No cables in a crane cab
Before, to get sensor signals to the crane cab, you had to run a cable along the bridge girder. The cable moved with the trolley and wore out quickly. We used a wireless weighing indicator. The sensor connects to a wireless transmitter. The cab gets a wireless receiver indicator. Range is 200 meters and it can go through two concrete walls. The maintenance electrician said: "Finally, I don't have to replace a cable every month."
Parameters and functions (table format)
|
Parameter |
Value |
|
Max transmission distance |
500 meters (line of sight), through 2 concrete walls |
|
Indicator battery |
Built-in rechargeable lithium, 72 hours continuous |
|
Enclosure |
ABS + TPE two-color injection, drop and slip resistant, IP65 |
|
Display |
4.3 inch TFT color screen, 500 cd/m² brightness, sunlight readable |
|
Keypad |
Large buttons, can be used with gloves |
|
Frequency band |
433 MHz or 2.4 GHz, 64 channels with auto-hopping |
|
Data refresh rate |
10 times/second |
|
Internal storage |
16 GB, stores 100,000 weighing records |
|
Interfaces |
USB (charging + data), micro printer port (Bluetooth or serial) |
Multiple scale management and cloud platform
One wireless weighing indicator can pair with up to 8 wireless scales (e.g., crane scale #1, hook scale #2). Switch between them with a button. The indicator has GPS. Each weighing record includes coordinates automatically. Data is uploaded to the cloud via 4G or Wi-Fi. Managers see real-time weight, history curves, and device online status remotely. There is also a mobile app as a second screen. A common question: "Can your wireless weighing indicator work with a scale that is 300 meters away?" Yes, but ensure line of sight. Yixing Silvanus Electric Manufacture Co., Ltd. has been making wireless products since 2007. Choosing us brings mobile weighing into the wireless age.
