See the weight 100 meters away at a truck scale
At a toll station in Hunan, the scale indicator was inside a booth. Truck drivers could not see the weight. That led to disputes. We installed a large display weight indicator with 6-inch digits. We hung it on the toll canopy. Drivers could see the weight clearly from 100 meters away. Disputes dropped by 80%. The station manager said: "That big screen was worth every penny."
Parameters and brightness (table format)
|
Parameter |
Value |
|
Protection class |
IP65, for all-weather outdoor use |
|
LED type |
Imported chips, red or bright green optional |
|
Brightness |
≥5000 mcd |
|
Digit heights |
4 inch, 6 inch, 8 inch, 12 inch |
|
Auto-dimming |
Built-in photosensor, adjusts brightness from 1 to 10 levels (night/day) |
|
Power supply |
220 VAC, power consumption ≤50W (depends on size) |
|
Communication |
RS485 standard, optional 4-20mA, Wi-Fi, 433 MHz wireless |
|
Mounting options |
Wall, pole, or gantry, with adjustable tilt |
Automatic signal type recognition
The large display weight indicator automatically detects the input signal. If it detects 4-20mA, it converts to weight (requires pre-set range). If it detects RS485 Modbus, it reads the specified register address. We also customize multi-line displays (gross, tare, net at the same time), scrolling text (e.g., "Please drive onto scale"), and audible/visual alarms (flashing and buzzer on overload). A common question: "Can your large display weight indicator be seen in direct sunlight?" Yes, 5000 mcd brightness is sunlight readable. Yixing Silvanus Electric Manufacture Co., Ltd. has been making industrial displays since 2007. Choosing us puts weight information across your entire work area.
