A truck scale customer has used it for eight years
In 2016, a coal mine in Henan bought our truck load cell for their weighbridge. Capacity was 100 tons. At that time, they thought Chinese-made sensors might not last. But until this year, all eight truck load cells are still working. None have failed. We tested this truck load cell. After 5 million fatigue cycles, performance dropped less than 0.1% FS. The client said: "If I had known, I would have changed all my scales to yours." Good products prove themselves over time.
Full Technical Parameters (Table Format)
|
Parameter |
Value |
|
Capacity range |
10 tons to 100 tons |
|
Accuracy class |
C3 or C4 (OIML R60) |
|
Max. verification intervals |
4000 |
|
Structure |
Double shear beam |
|
Elastic body material |
40CrNiMoA high nickel alloy steel |
|
Yield strength |
≥900 MPa |
|
Surface coating |
Polyurethane, thickness ≥80μm |
|
Salt spray resistance |
≥500 hours |
|
Strain cavity sealing |
Fully welded (laser + argon arc) |
|
Protection class |
IP68 (2m water for 7 days) |
|
Cable sheath |
Polyurethane, oil resistant, UV resistant, -40℃ |
Why it is good for outdoor weighbridges
First, it has a built-in lightning protection module. Gas discharge tube plus transient suppression diode. It withstands 10kV/5kA surges. Second, we have a 6-wire version with sense wires. It compensates for voltage drop over 500 meters of cable. Third, we give a stainless steel junction box with precision potentiometers. Easy angle adjustment on site. A common question: "Can your truck load cell survive winter freezing?" Yes, down to -40℃. Yixing Silvanus Electric Manufacture Co., Ltd. has been making heavy-duty sensors since 2007. Choosing us gives you a rugged sensor that lasts eight or nine years in all weather.
