Why an elevator maker stays with us for six years
An elevator factory in Suzhou has worked with us for six years. They use this elevator load cell. Capacity is 1000 kg. It mounts under the car floor. Our elevator load cell responds in less than 10 milliseconds. When the load reaches 110% of rated capacity, it alarms and prevents the door from closing. The client said that in six years, not a single elevator had an accident due to the sensor. Safety is not something to take lightly.
Full Technical Parameters (Table Format)
|
Parameter |
Value |
|
Capacity range |
400 kg to 2000 kg |
|
Accuracy |
1% FS |
|
Response time |
<10 ms |
|
Elastic body material |
40CrNiMoA alloy steel |
|
Surface |
Hard chrome plated, hardness ≥HV800 |
|
Structure |
Double shear beam or ring type |
|
Creep (30 min) |
≤ ±0.02% FS (optimized for frequent stops) |
|
Protection class |
IP65 |
|
Mounting holes |
Standard elevator industry size |
|
Output options |
4-20mA analog or CANopen digital |
|
Compatibility |
Monarch, STEP, Blue Light, and other mainstream systems |
Dual output: double safety
We offer a dual independent output version. The two signals back each other up. If one path fails, the other takes over immediately and sends an alarm. The elevator load cell also has a built-in temperature compensation chip and self-diagnostic circuit. Broken wire, overload, or zero drift all trigger a fault code output. A common question: "Can your elevator load cell handle frequent start-stop wear?" Yes, the creep performance is specially optimized for that. Yixing Silvanus Electric Manufacture Co., Ltd. has been making safety sensors since 2007. Choosing us puts a double safety net on every elevator.
