The 500℃ test in a foundry
A foundry in Shanxi needed to weigh molten steel ladles online. The ambient temperature was near 500℃. We used a high-temperature load cell plus a water cooling jacket. The sensor body used Inconel high-temp alloy. After cooling water flowed through, the sensor temperature stayed below 70℃. The customer has used it for two years. None have failed. They said: "Your high-temperature load cell really resists heat."
Full Technical Parameters (Table Format)
|
Parameter |
Value |
|
Long-term working temperature |
-40℃ to +250℃ |
|
Short-term tolerance |
300℃ (30 minutes) |
|
Capacity range |
100 kg to 100 tons |
|
Accuracy class |
C3 |
|
Creep at high temp |
≤ ±0.03% FS/30min |
|
Elastic body material |
Inconel 718, strength at 650℃ |
|
Strain gauge type |
High temperature type, -50℃ to +250℃ |
|
Adhesive |
Ceramic glue |
|
Heat shields |
Stainless steel reflective layer + aerogel |
|
Output cable |
Glass fiber braided, -60℃ to +400℃ |
Water-cooled version: withstands 500℃
If your temperature exceeds 250℃, we offer a water-cooled version. The high-temperature load cell has internal water channels. Feed 5-25℃ cooling water. The sensor body stays below 70℃. This allows regular high-temp strain gauges to work in 500℃ environments. We also integrate a PT100 temperature sensor inside. It monitors the body temperature in real time and alarms if overheated. A common question: "Can your high-temperature load cell work in a vacuum furnace?" Yes, but please confirm your vacuum level with us. Yixing Silvanus Electric Manufacture Co., Ltd. has been making high-temp sensors since 2007. Choosing us means high temperature is no longer a barrier to weighing.
